1 Set EDF Full Metal Ducted Fan JP 90mm with Three Choice Motor 4250 KV1750 6S KV1330 8S 10S KV1050 12S Motor for Jet RC

100% CNC aluminium JP Hobby EDF unit (shroud and rotor) for 6s.
The V2 version offers an exceptional reduced gap of 0.25mm between each blade edge and the EDF shroud for more efficiency.
Jingpin Hobby uses High grade aluminium alloy material for highest rigid structure and lightest weight.
The shroud acts as a heat sink, removing heat from the motor. This design creates a more efficiently running motor and will
provide peak performance while extending the lifespan of the motor.
The highly rigid structure design is capable of running up to 88,000 RPM to produce extremely high efflux velocity for maximum
speed and efficiency.
Anti Blade flying out design,the Blades be safety kept in the shroud and without damage.It is the best replacement for your
plastic or carbon shroud if you want to have a safety EDF fan.
Each metal blade is precisely made of High Grade Aluminum alloy to generate jet airflow. Every blade has been tested for 8 hours
of metal fatigue test as well as in the dynamic balance machine for calibration, making it bring a better and safer user
experience for every RC fan.
You could assemble our EDF system with any other motor without losing dynamic balance effect.
The motor and fan unit comes assembled and balanced from the factory.
Specifications:
Length (mm): 74.12mm (without motor / Cone)
Weight (gr): 459 gr
EDF Diameter Class (mm): 90
EDF Outside Diameter (mm):94.5 mm
EDF Inner Diameter (mm) :90.5 mm
Rotor Diameter (mm): 90 mm
Stators: 8
Motor Type: Out-Runner
Blades: 12
Working voltage (Volts/LiPo Cells):22.2v / 6s
Turns/min/Volt (Kv):1750 Kv
Motor Diameter (mm):42.65 mm
Shaft diameter (mm):5
Connection: Pk 5mm
