Key attributes
Other attributes
place of origin
Guangdong, China
brand name
Hobbywing
model number
X9
private mold
NO
Max.Thrust
19.2kg/Axis (46V, Sea Level)
Recommended LiPo Battery
12S LiPo
Recommended Takeoff Weight
7-9.5kg/Axis (48V, Sea Level)
Combo Weight
1400g
Waterproof Rating
IPX7
Operating Temperature
-20℃~55℃
Stator Size
96*16mm
Propeller
34.7*11 inch
Certification
ce
Packaging and delivery
Selling Units:
Single item
Single package size:
40X10X10 cm
Single gross weight:
2.000 kg
Product descriptions from the supplier
Warning/Disclaimer
Compliance Reminder for Prohibited and Restricted productsView more
California Proposition 65 Consumer WarningView more
|
X9 Power System Combo
|
||||
|
Specifications
|
Max. Thrust
|
19.2kg/Axis (46V, Sea Level)
|
||
|
Recommended LiPo Battery
|
12S LiPo
|
|||
|
Recommended Takeoff Weight
|
7-9.5kg/Axis (46V, Sea Level)
|
|||
|
Combo Weight
|
1400g
|
|||
|
Waterproof Rating
|
IPX7
|
|||
|
Operating Temperature
|
-20℃~55℃
|
|||
|
Motor
|
Quter Diameter
|
96*16mm
|
||
|
KV Rating
|
110KV
|
|||
|
O.D of Carbon Fiber Tube
|
φ40
|
|||
|
Bearing
|
Imported Waterproof Bearing
|
|||
|
ESC
|
Recommended LiPo Battery
|
6-12S LiPo
|
||
|
PWM Input Signal Level
|
3.3V/5V (Compatible)
|
|||
|
Throttle Signal Frequency
|
50-500Hz
|
|||
|
Operating Pulse Width
|
1100~1940μs (Fixed or cannot be programmed)
|
|||
|
Max. Input Voltage
|
52.2V
|
|||
|
Max. Input Current (Cont.)
|
120A (w/Good Heat Dissipation)
|
|||
|
Max. Peak Current (10s)
|
150A (w/Good Heat Dissipation)
|
|||
|
BEC
|
No
|
|||
|
Nozzle Mounting Holes
|
φ28.4mm-2*M3
|
|||
|
Propeller
|
Diameter*Pitch
|
34.7*11inch
|
||
