Technical parameter
Maximum tension (46V) : 11.8kg
Recommended lithium battery saving: 12-14S
Recommended takeoff weight: 3.5-5.5kg
Powertrain weight: 790g
Applicable carbon tube size: 30mm
Applicable ambient temperature: -20-50℃
Protection level: IPX6
Recommended lithium battery saving: 12-14S
Recommended takeoff weight: 3.5-5.5kg
Powertrain weight: 790g
Applicable carbon tube size: 30mm
Applicable ambient temperature: -20-50℃
Protection level: IPX6
Motor
Motor model: 6218
KV value: 150rpm/V
Motor outer diameter: 69.4mm
KV value: 150rpm/V
Motor outer diameter: 69.4mm
Propeller
Diameter/pitch : 24*8.0inch
Blade assembly weight : 107g
Single blade weight : 33.5g
Blade assembly weight : 107g
Single blade weight : 33.5g
ESC
Model: 80A-FOC
PWM input signal level: 3.3V/5V
Working pulse width: 1050-1950 μs
Operating frequency: 50-500Hz
Maximum allowable voltage: 61V
Continuous current (non-closed environment temperature ≤60℃) : 25A
Maximum current (non-closed environment temperature ≤60℃) : 80A
PWM input signal level: 3.3V/5V
Working pulse width: 1050-1950 μs
Operating frequency: 50-500Hz
Maximum allowable voltage: 61V
Continuous current (non-closed environment temperature ≤60℃) : 25A
Maximum current (non-closed environment temperature ≤60℃) : 80A
